Odyssey Extreme AGM Battery PC680

Dimensions:

• Length: 7.20 in
• Width: 3.00 in
• Height (terminals included): 6.40 in
• Height (container): 6.60 in
• Weight: 15.40 lbs

Specifications:

• Voltage: 12V
• Pulse (5 second) Hot Cranking Amps (PHCA): 520A
• Cold Cranking Amps (CCA): 170A
• HCA: 350A
• MCA: 280A
• 20Hr Nominal Capacity (Ah): 16ah
• 10Hr Nominal Capacity (Ah): 16ah
• Reserve Capacity Minutes: 24 mins
• Terminal: M6 Receptacle
• Torque Spec in-lbs (Nm max): 50 (5.6)
• Internal Resistance (mΩ): 7
• Short Circuit (A): 1800A
• Recommended Min. Charging Current (A): 1.6A
• Operating Temperature Range: -40°F / -40°C to 113°F / +45°C
• Optimum Storage Temperature: 68°F / +20°C
• UPC: 635241140996
